Hpe Acceltex Acceltex Universal Ap All-Thread Drop Mount Ex Demo Opened

Product Description

The AccelTex Solutions Universal AP All-Thread Drop Mount is a specialized mounting solution designed for indoor wireless access points (APs). It solves the common installation challenge of mounting enterprise APs in facilities with high, open ceilings—such as warehouses, gymnasiums, and manufacturing floors—or when installing equipment discreetly below a suspended ceiling grid.

By using standard 3/8" threaded rods (all-thread) or beam clamps, this mount allows installers to drop the AP and its antennas down to an optimal height for clean wireless line-of-sight and improved RF performance. To mount, the AP's built-in mounting feet simply slide and snap securely into the pre-defined keyholes on the bracket, or the installer can utilize the standard T-Bar mount adapter supplied with the access point.

(Note: Since this specific unit is marked as "Ex Demo Opened," it is a previously opened display or demonstration model, meaning it may show minor superficial handling marks, but the structural integrity of the steel bracket remains fully functional).

Key Features

• Universal Enterprise Compatibility: Designed to seamlessly host standard T-Bar mounted APs from leading networking brands, including HPE / Aruba, Cisco Catalyst / Meraki, Mist, and Arista.

• Flexible Hanging Options: Accommodates drops using a 3/8” All-Thread rod or can be securely fastened using a standard beam clamp.

• Snap-In Installation: The physical design features built-in, pre-defined keyhole slots, allowing compatible APs to slide and lock securely into place without complex assembly.

• Rugged Steel Construction: Made of heavy-duty, solid steel with a clean white powder-coat finish to blend into commercial ceilings and resist wear.

• Optimize RF Signal Coverage: Allows APs and antennas to be lowered in high-ceiling structures, bypassing physical obstructions (such as pipes, HVAC ducts, and steel beams) that would otherwise degrade wireless signals.

Technical Specifications

• Dimensions: 7.3” L x 7.1” W x 4.3” H (185mm L x 180mm W x 110mm H)

• Weight: 1.5 lbs (0.68 kg)

• Material: Solid Steel

• Color: White

• Environment: Rated for Indoor use only

• Required Hardware (Not Included): 3/8” All-Thread rod, fasteners, or beam clamp (must be supplied by the installer).
